Spécifiquement pour Deep Sea Electronics Modul de la mer profonde - Contr?leur DSE8610 MKII DSE8610MKII

Introducing the Controller DSE8610 MKII for Deep Sea Electronics Deep Sea Module, the latest innovation in complex load sharing and synchronizing control technology. Designed specifically to handle the most complex grid type generator applications, the DSE8610 MKII control module offers a wide range of features and benefits that are unrivalled in the generator control industry.

With an overall size of 245 mm x 184 mm x 51 mm (9.6″ x 7.2″ x 2.0″) and a panel cutout size of 220 mm x 160 mm (8.7″ x 6.3″), the DSE8610 MKII is compact yet powerful. It can easily fit into most control panel configurations with a maximum panel thickness of 8.0 mm (0.3″).

The DSE8610 MKII is available in the 8610-02 variant, which is a synchronizing and load sharing control module with CT and RTC capabilities. This variant ensures seamless synchronization and load sharing between multiple generators, providing a reliable and efficient power supply.

One of the key features of the DSE8610 MKII is its continuous voltage rating of 8 V to 35 V. It can withstand cranking dropouts of 0 V for 50 mS, as long as the supply voltage was at least 10 V before the dropout and recovers to 5 V. This eliminates the need for internal batteries, making it highly convenient and cost-effective.

The DSE8610 MKII has a maximum operating current of 460 mA at 12 V and 245 mA at 24 V, ensuring optimal performance and efficiency. Its maximum standby current is 375 mA at 12 V and 200 mA at 24 V, allowing for energy-efficient standby mode. With a charge fail/excitation range of 0 V to 35 V, the control module provides reliable and uninterrupted power output.

In terms of outputs, the DSE8610 MKII comes with Output A (Fuel) and Output B (Start), both capable of delivering 15 A DC at the supply voltage. These outputs ensure precise fuel control and efficient starting of the generator, minimizing downtime and maximizing productivity.

The DSE8610 MKII control module represents the epitome of advanced and reliable generator control technology. It offers unparalleled performance, functionality, and ease of use, making it the preferred choice for complex grid type generator applications. Upgrade to the DSE8610 MKII and experience the power of innovation in generator control.
